The AI fully automated X-ray diffractometer deeply integrates the high-precision manipulation of a robotic arm based on a portable diffractometer. Compared to traditional diffractometers, it significantly reduces manual intervention, making it suitable for R&D scenarios requiring high-throughput and high-repeatability testing. It can be remotely controlled via mobile phone or APP, featuring automatic door opening and closing technology. With autonomous sampling and analysis capabilities, it offers precision and convenience.

Fiber Accessories utilize the X-ray diffraction (transmission) method to analyze the unique crystal structure of fibers. Parameters such as crystallinity and full width at half maximum (FWHM) are used to determine the orientation degree of the sample. ​ Main Functions and Features of Fiber Accessories: Maintaining Fiber Orientation: This is the most critical aspect. Fibers typically exhibit high anisotropy, with crystals preferentially aligned along the fiber axis. Fiber Accessories can straighten and secure fiber bundles, preserving their original orientation to measure orientation degree and distribution. Adapting to Different Sample Forms: Single Fiber: Extremely thin, requiring special clamps or frames for fixation. Fiber Bundle: Multiple fibers arranged in parallel; Fiber Accessories must align and tension them uniformly. Fiber Fabric: Materials like cloth require a flat frame to stretch them taut. Enabling Special Testing Modes: Transmission Mode: Suitable for thin fiber bundles or single fibers. Fiber Accessories include a dedicated frame to tension the fiber, allowing X-rays to penetrate the sample directly. Reflection Mode: Used for thicker fiber bundles or fabrics. Fiber Accessories provide a flat sample surface for this mode. Fiber Sample Holder: This is a simple metal or plastic frame equipped with slots or knobs. During operation, both ends of the fiber bundle are fixed to the holder, and knobs are rotated to tension the fiber, keeping it straight and parallel. The entire holder can be placed in the XRD goniometer for testing, similar to a standard sample. In summary, Fiber Accessories for XRD are specialized sample fixation devices designed for testing fibrous samples with anisotropic structures. Their core function is to maintain and regulate fiber orientation, while advanced versions may support in-situ stretching and other functionalities, providing critical insights into the orientation of crystal structures in fibers.

In the field of lithium-ion battery research and development, understanding the dynamic changes in the microstructure of electrode materials during charge and discharge processes is crucial. Traditional offline detection methods cannot capture these changes in real time, while the emergence of in situ characterization techniques provides researchers with a powerful tool. Leveraging its expertise in X-ray diffraction (XRD) technology, Dandong Tongda Technology Co., Ltd. has developed an in situ battery accessory for battery research, offering an efficient window to explore the reaction processes inside the "black box" of batteries. Technical Principle: Dynamically Monitoring Microscale Changes in Battery Materials The core design goal of Dandong Tongda's originally battery accessory​ is to enable real-time monitoring of the evolution of the crystal structure of electrode materials using X-ray diffraction (XRD) technology while the battery is operating normally (during charge and discharge). This accessory typically needs to work in synergy with an electrochemical testing system (such as the LAND battery test system) and an X-ray diffractometer (such as Tongda Tech's TD-3500 model). It forms a specialized battery chamber that allows X-rays to penetrate and probe the electrode materials of the battery during operation. The key lies in the design of window materials (such as beryllium windows) with extremely low X-ray absorption rates on the battery components, ensuring effective incidence and emission of X-rays. Simultaneously, the accessory integrates necessary electrodes, insulation, and sealing components to ensure normal electrochemical reactions and maintain excellent sealing during testing. Key Functions and Application Value The value of this in situ battery accessory lies in its ability to help researchers intuitively and dynamically observe a series of microscopic changes in electrode materials during battery charge and discharge processes: Real-Time Observation of Phase Transition Processes: Many electrode materials undergo phase transitions during lithium-ion intercalation and deintercalation. In situ XRD can capture the formation, disappearance, and transformation of these phases in real time, which is critical for understanding the battery's reaction mechanisms. Monitoring Lattice Parameter Changes: By precisely tracking the shifts in XRD diffraction peaks, subtle changes in lattice parameters can be calculated, reflecting the expansion and contraction of the lattice. This is closely related to battery performance metrics such as voltage platforms and cycle life. Unveiling Capacity Decay Mechanisms: Capacity decay during battery cycling is often related to structural degradation of electrode materials, side reactions, and other factors. In situ monitoring can correlate electrochemical performance degradation with structural changes, providing direct insights for improving battery materials and optimizing design. Accelerating New Material Development: For evaluating novel electrode materials, in situ XRD technology can quickly provide key information on structural stability and reaction pathways, speeding up the R&D process.

As a well-known enterprise in the field of domestic precision instruments, Dandong Tongda Technology Co., Ltd. has launched a series of multi-function sample holder products. With high precision, modular design, and extensive application scenarios, these products have become one of the core equipment in material analysis, X-ray diffraction (XRD), and other fields. Core Functions: Meeting Diverse Analytical Needs Material Structure Analysis: Used for crystalline phase detection, orientation degree (texture) analysis, and residual stress testing, supporting the analysis of materials such as metals, ceramics, and thin films. In-plane rotation (β-axis) eliminates preferred orientation, ensuring the reproducibility of diffraction intensity data. Environmental Simulation Function: Optional high-temperature, low-temperature, or vacuum atmosphere modules (e.g., liquid nitrogen temperature control devices) support variable temperature testing from -196°C to 1000°C, meeting special requirements for high-temperature superconducting materials, metal surface treatment, and more. Automation and Intelligence: Supporting software enables automatic scanning, multi-point measurement, and data linkage analysis, improving detection efficiency. Application Fields: From Scientific Research to Industrial Testing Dandong Tongda sample holder are widely used in the following fields: Materials Science: Texture evaluation of rolled metal sheets, orientation analysis of ceramics, and residual stress testing of thin films. Semiconductor Industry: Analysis of multilayer films on silicon substrates (e.g., magnetic films, hardened coatings). Energy and Environmental Protection: Microstructural research on high-temperature superconducting films, battery materials, and catalysts. Higher Education and Scientific Research: Experimental teaching and research projects in crystallography, quantitative phase analysis, and more. Conclusion: An Indispensable Tool for Material Microanalysis The Dandong Tongda Multi-Function Sample Holder, with its high-precision motion control, modular flexibility, and broad environmental adaptability, has become an indispensable tool for material microanalysis. Its technical advantages are deeply rooted in the company's years of accumulated expertise in X-ray diffraction technology, combining research-grade precision with industrial-grade reliability to help users unlock the secrets of material properties at the microscopic scale. The multi-function sample stage serves as the "hands and feet" of modern precision observation and measurement, precisely presenting samples within the "field of view" of analytical instruments. Its selection directly determines the feasibility, efficiency, and reliability of experiments. Understanding its basic principles, functional classifications, and technical specifications is key to selecting and effectively utilizing this equipment.

Dandong Tongda XAFS Spectrometer: A Material Structure Analysis Tool for the Laboratory Precise analysis of atomic material structure without dependence on synchrotron radiation sources. X-ray Absorption Fine Structure (XAFS) spectroscopy serves as an important technique for investigating the local atomic and electronic structures of materials, with broad applications in catalysis, energy research, and materials science. Conventional XAFS methodology primarily relies on synchrotron radiation sources, which presents challenges including limited beam availability, complex application procedures, and the necessity to transport samples to large-scale scientific facilities for analysis. The X-ray Absorption Fine Structure developed by Dandong Tongda Technology Co., Ltd. aims to integrate this sophisticated analytical capability into standard laboratory environments. Core Advantages and Practical Value This instrument's design addresses several critical challenges researchers encounter: Laboratory-Based Alternative to Synchrotron Radiation: Eliminates the traditional dependency on synchrotron radiation sources, enabling researchers to conduct routine XAFS testing efficiently within their own laboratory settings, thereby significantly enhancing research productivity. In-Situ Testing Capabilities: Supports integration of various in-situ sample chambers (e.g., electrochemical, temperature-variable), enabling real-time monitoring of dynamic changes in material local atomic structure under simulated operational conditions (such as catalytic reactions or battery charge/discharge processes), providing valuable insights into reaction mechanisms. Automated Operation for Enhanced Efficiency: An 18-position sample turret enables automatic sample changing, facilitating continuous automated measurement of multiple samples and unmanned operation, thereby streamlining batch sample screening and extended in-situ experiments. Broad Application Scope The TD-XAFS spectrometer finds applications across numerous fields requiring detailed investigation of material local structures: New Energy Materials: Analysis of valence state changes and structural stability in lithium-ion battery electrode materials during charge/discharge processes; investigation of coordination environments at catalytic active sites in fuel cells. Catalysis Science: Particularly suitable for studying precise coordination structures of nanocatalysts and single-atom catalysts, active site characteristics, and their interactions with support materials, even at low metal loadings (<1%). Materials Science: Investigation of disordered structures, amorphous materials, surface/interface effects, and dynamic phase transition processes. Environmental Science: Analysis of valence states and coordination structures of heavy metal elements in environmental samples (e.g., soil, water), crucial for assessing toxicity and mobility. Biological Macromolecules: Study of electronic structures and geometric configurations of metal active centers in metalloproteins and enzymes. Summary Dandong Tongda's TD-XAFS spectrometer represents a high-performance domestic benchtop testing platform designed for universities, research institutions, and corporate R&D centers. It successfully incorporates synchrotron-level capabilities into conventional laboratories, substantially reducing the accessibility barrier to XAFS technology. The instrument provides researchers with convenient, efficient, and flexible tools for microscopic material structure analysis, serving as a practical solution for scientists exploring the microscopic world of matter.

In research fields such as life sciences, radiation biology, and pest control technology, precise, safe, and controllable irradiation methods are fundamental to many critical experiments. Leveraging its expertise in X-ray technology, Dandong Tongda Technology Co., Ltd. has developed the WBK-01 X-ray Irradiator, designed to provide a modern alternative to traditional radioactive isotope sources for various laboratories. I. Core Principle and Design Purpose The equipment operates by accelerating electrons through a high-voltage electric field to strike a metal target (e.g., a gold target), thereby generating high-energy X-rays. This design of an "electrically generated radiation source" fundamentally avoids the use of radioactive isotopes like Cobalt-60 (Co-60) or Cesium-137 (Cs-137), eliminating the long-term custody, substantial decommissioning costs, and potential safety hazards associated with source materials. II. Core Product Features High Safety: No Radiation When Powered Off: X-rays are only generated when the equipment is powered on and operating. There is no residual radiation after operation, significantly reducing laboratory security and management costs. Multiple Safety Interlocks: Equipped with multiple safety protection features including door-operation interlock, emergency stop, and overdose protection, ensuring the safety of operators and the environment. Precise Control and Good Reproducibility: Utilizes a digital control system, allowing users to precisely set irradiation parameters—including voltage (kV), current (mA), and irradiation time—via a touchscreen interface. The system enables stable dose output, ensuring uniformity in experimental conditions and reproducibility of results. Easy Operation and Simple Maintenance: The user interface is simple and intuitive, easy to learn and operate, lowering the barrier to use. Compared to isotope sources which require regular replacement and decay monitoring, the main maintenance for this equipment focuses on the periodic replacement of the X-ray tube, resulting in relatively fixed and manageable long-term maintenance costs. Flexible Sample Compatibility: The irradiation chamber is designed to accommodate various samples, from cell culture dishes and multi-well plates to small animals (e.g., fruit flies, mosquitoes, or mice). The sample stage can be designed to rotate, ensuring uniformity in radiation dose distribution. III. Main Application Scenarios Biomedical Research: Used for creating immunodeficient animal models (e.g., ablating bone marrow cells in mice), inducing cell apoptosis, synchronizing cell cycles, oncology research, and pre-treatment for stem cell transplantation. Sterile Insect Technique (SIT): This is a significant application area. It can be used to irradiate pupae of agricultural pests (e.g., Mediterranean fruit fly) or mosquitoes to render them sterile, thereby supporting green, pollution-free population control programs. Material Modification Research: Can be used to study the effects of X-rays on the properties of various materials (e.g., polymers, semiconductors). IV. Typical Model Parameters (Using WBK-01 as an example) X-ray Tube Voltage: Adjustable based on requirements, typically within a range from several tens to hundreds of kilovolts (kV), to suit different penetration depths and dose rate needs. Dose Rate: Can be adjusted based on voltage, current, and distance to meet the specific requirements of different experimental protocols. Uniformity: Ensured through optical system design and a sample rotation mechanism, guaranteeing uniform dose distribution within the irradiation field for reliable experiments. Summary The core value of the Dandong Tongda X-ray Irradiator lies in its replacement of inconvenient radioactive isotope sources with a safe, controllable, electrically generated X-ray source. It does not pursue excessive features but focuses on providing a stable, reliable, compliant, and easy-to-manage irradiation tool for scientific research and industrial applications. For laboratories seeking alternatives to isotopes or planning to establish new irradiation platforms, this is a practical piece of equipment worthy of evaluation and consideration by users in basic research and applied fields.

The multi-functional residual stress analyzer developed by Dandong Tongda Technology Co., Ltd. is designed to meet the needs of fast and accurate measurements in both laboratory and field environments. Based primarily on the X-ray diffraction principle, it enables non-destructive testing of the residual stress state inside materials. Versatile All-in-One Analysis This analyzer integrates multiple material analysis functions, significantly enhancing equipment utility and efficiency: Residual Stress Analysis: Supports various measurement modes such as standard同倾法 (omega-inclination), standard侧倾法 (psi-inclination), and standard摇摆法 (oscillation), capable of determining principal stresses and shear stresses for a comprehensive stress state evaluation. Retained Austenite Analysis: Employs the four-peak method for retained austenite testing, with fully automated data calculation for quick results. Diffraction Phase Analysis: Used to analyze crystal structures, chemical composition content, and distribution, helping researchers gain deeper insights into material constitution. Grain Size Analysis: Supports grain size evaluation from nanoscale to sub-micron scale, particularly suitable for fine grains ≤200 nm. Technical Features and Performance This instrument boasts multiple technical features aimed at ensuring precision, stability, and ease of use: High-Precision Measurement and Control: Utilizes a high-precision fully closed-loop vector drive servo system to ensure measurement accuracy and repeatability. Efficient Data Acquisition: Equipped with a multi-channel silicon strip linear array detector, which provides noise-free performance, high-intensity measurement, and rapid data collection to enhance detection efficiency. Portable Design: Features a lightweight construction, making it suitable not only for laboratory environments but also for on-site rapid measurements, adapting to various testing scenarios. User-Friendly Operation: Integrates Windows OS or automation functions, supporting one-click testing and real-time result display, lowering the operational barrier. Modularity and Safety: Employs a PLC control system with modular design for ease of operation and stable performance. Safety-wise, its low-power X-ray design complies with relevant safety standards, with radiation levels significantly below the annual public dose limit. Broad Application Fields Dandong Tongda’s multi-functional residual stress analyzer has extensive applications, covering almost all industrial sectors and research institutions requiring evaluation of material mechanical properties: Manufacturing Quality Control: Used to detect residual stresses in stamped, cast, and rolled parts during processing. Automotive Industry: Tests residual stresses in critical components such as camshafts and connecting rods to ensure reliability and durability. Aerospace: Evaluates working loads in critical areas of aerospace materials to assess safety. Materials Science Research: Applicable to various metal materials (e.g., carbon steel, alloy steel, titanium alloy, nickel-based materials), glass, and composite materials for residual stress, retained austenite, phase, and grain size analysis. Dandong Tongda Technology Co., Ltd.’s multi-functional residual stress analyzer demonstrates the company’s technical expertise in the field of material testing by integrating multiple analytical functions. This instrument provides engineers and researchers with a window into the intrinsic stress state of materials, helping to control product quality at the source, optimize process parameters, and thereby enhance product reliability and durability.
