Single Crystal XRD

TD-5000 X-ray single crystal diffractometer(single crystal xrd)

Hybrid pixel detector is a revolutionary development in the field of X-ray detectors that enables better date quality while ensuring low power consumption and cooling. The detector combines the key technology single photo counting and hybrid pixel for applications in various fields such as synchrotron radiation and conventional laboratory light sources to eliminate the interference of readout noise and dark current. Hybrid image cable technology can directly detect X-ray signals that are more distinguishable. And the detector is highly efficient at delivering high quality data from your more challenging samples.

TD-5000 X-ray single crystal diffractometer product introducteion

Domestic exclusive- to fill the domestic gap

Piltus Mixed Pixel Detector

TD-5000 X-ray single crystal diffractometer（single crystal xrd) is mainly used to measure the three-dimensional spatial structure and electron cloud density of inorganic and organic materials. The hybrid pixel detector provides the best data quality while ensuring low powerconsumption and low cooling. The detector combines the two key technologies of single photoncounting and mixed pixels, it is used in various fields such as synchrotron radiation and conventioral laboratory light source, effectively eliminate the interference of reading noise and dark current,hybrid pixel technology can detect X-rays directly, easier to resolve the signal, and the detector can efficiently provide high quality data.

Cryogenig Equipment：

The data collected through the cryogenic equipment has more ideal results, and under the actionof the cryogenic equipment, more advantageous conditions can be improved, which may make theimperfect crystal obtain ideal results. The ideal crystal can also obtain more ideal results.

Temperature control range: 100K~300K

Liquid nitrogen consumption: 1.1-2L/H

Control accuracy: 土0.3K

Single  Crystal  XRD

Instrument accuracy：

2θangle repetition accuracy：0.0001°；

Minimum index angle：0.0001°；

Temperature control rang：100K—300K

Control accuracy：±0.3K

TD-5000 X-ray single crystal diffractometer(single crystal XRD) adopts the four-circle concentric technology to ensure that the center of the goniometer remains unchanged no matter how the rotation occurs. To achieve the purpose obtaining the most accurate date and obtaining a higher integrity rate, and the four concentric circles are necessary conditions for routine single scanning. And it carries a detector that makes higher data quality and faster scanning.

Detector Features：

Sensitive area [mm2]：83.8 × 70.0

Pixel size [µm2]：172 × 172

Pixel spacing：< 0.03%

Max collar rate[Hz]：20

Read out time [ms]:7

Energy range [keV]:3.5 - 18

Test results：

Optional attachments：

Multilayer film focusing lens：

X-ray tube rate：30W or 50W；Divergence：0.5~1 mrad；

X-ray tube target：Mo / Cu spot；Focal spot：0.5~2 mm。

Sales performance：

The technical personnel of the company have completed the installation and debugging of the foreign single crystal X-ray diffractometer, and the test results are very satisfactory to the foreign users. Function, stability and after-sales service by foreign users of the unanimous praise.

Distinctive Core Advantages

Technological Pioneer Filling Domestic Gaps
Tongda is a contractor of the National Major Scientific Instruments and Equipment Development Special Project. In 2013, it established the Academician Expert Workstation with Academician Chen Xiaoming. In 2021, the first domestically produced X-ray single crystal diffractometer with independently developed intellectual property rights, manufactured by Tongda, was officially launched into the market.

An Innovative Enterprise Driven by R&D
The company's R&D personnel account for as much as 30% of its workforce, holding a total of 23 patents and 7 software copyrights. Its product portfolio covers the entire series, including TD series diffractometers, benchtop diffractometers, absorption spectrometers, X-ray single crystal diffractometers, crystal orienters, and crystal analyzers, establishing itself as a professional manufacturer of X-ray analytical instruments.

Pioneer in Deep Integration of AI with Robotic Arms
Tongda's AI fully automated diffractometer achieved an early integration of high-precision robotic arm control with AI technology in the industry. Key features include: support for automatic sample loading of various types such as powders, thin films, and blocks; remote control via a mobile phone APP with automatic door opening/closing for enhanced testing safety; and a modular design facilitating easy upgrades and maintenance, enabling "plug-and-play" functionality.

The Fundamental Value of Choosing Tongda
What you acquire is not just an instrument, but also: continuous technical support from the academician expert team, a technological heritage that fills domestic gaps, rapid response backed by a 30% R&D team, and system integration experience from national major special projects.

Tongda has always believed that: Quality is life, Credibility is the foundation, Innovation is the driving force, and Talent is the resource — this is the essential difference between us and ordinary equipment suppliers.
